Heavy Duty 26'' 12G 48 Spokes Bike Wheel Set Front & Rear Rim - MTB Road





NOTE: It's inevitable that there will be SCRATCHES or PAINT PEELING during transportation, order carefully if you are concerned.

Please kindly note:

Before installing, please clean the metal scrap in hub firstly;

And put engine oil or lubricating oil on the axle and the six screw holes to disc brake to prevent the screw from damaging!

NOTE:Excluding 6 Bolts

26 inch Heavy Duty Bike Rim Wheels Set, 12 Gauge 48 Spokes Wheelset, Double Wall Aluminum Alloy 26" Bicycle Rims Set (Front & Rear) (Black) Disc Brake

• 26 inch Heavy Duty Double Wall Aluminum Alloy Bike Rims Set; 12 Gauge 48 Spokes Wheels Set
• Front Hub Width 100mm, Axle Length 145mm; Rear Hub Width 135mm, Axle Length 180mm
• Rim Diameter: 22.44 inch (570mm); Rim Width: 1.85 inch (47mm); Rim Inner Width: 1.54 inch (39mm); Hub Diameter: 1.18 inch (30mm)
• Fit 26x2.35"-3.5" Tires; Disc Brake and Caliper Brake
• Disc brake and 44mm spacing of center hole to center hole

• Fit Single Speed and 7/8/9s Multi-Speed Rotary Flywheel
• Suggestion:For Double Security,MUST Recheck and Readjust the Spoke Tension with tools REGULARLY or MUST go to bike shop if ride for Gas motorized bicycle.

26 inch Heavy Duty Bike Rim Wheels Set, 12 Gauge 48 Spokes Wheelset, Double Wall Aluminum Alloy 26" Bicycle Rims Set (Front & Rear) (Black) Disc Brake
Details for Rim SizeRim Size 22.44 inch/570mm

• Aluminum Alloy
• 12 Gauge
• Heavy Duty
• Double Wall

Rim Width 1.85 inch/47mm

• Rim Width 1.85 inch/47mm
• Rim Inner Width: 1.54 inch (39mm)
• Double Wall Aluminum Alloy

Details for Rear RimRear Rim

• Material: Aluminum Alloy
• Sealed Bearings 6200 RS
• 6 holes for disc brake
• Hub Diameter 1.18 inch (30mm)

12 Gauge Heavy Duty 48 Spokes

• Rear Width 135mm, Axle length 180mm
• Fit Single Speed and 7/8/9s Multi-Speed Rotary Freewheel
• 12 Gauge Heavy Duty Double Wall Rim
• 48 Spokes

Details for Front RimFront Rim

• Material: Aluminum Alloy
• Sealed Bearings 6200 RS
• 6 holes for disc brake
• Hub Diameter 1.18 inch (30mm)

12 Gauge Heavy Duty 48 Spokes

• Front Width 100mm, Axle length 145mm
• 12 Gauge Heavy Duty Double Wall Rim
• 48 Spokes
